| Place of Origin: | American |
|---|---|
| Brand Name: | SUN |
| Certification: | cc |
| Model Number: | NQEB-XAN |
| Minimum Order Quantity: | 1 |
| Price: | RMB/1000-10000/PC |
| Packaging Details: | wooden case/carton |
| Delivery Time: | 3days |
| Payment Terms: | T/T |
| Supply Ability: | 10PCS/days |
| Brand: | SUN | Model: | NQEB-XAN |
|---|---|---|---|
| Valve Configuration: | 2-Way | Leakage Rate: | Less Than 1 Drop Per Minute |
| Horsepower: | 0.04 | Flow Rate: | Ranges From 5 Gpm To 30 Gpm |
| Fluid Compatibility: | Mineral-based Hydraulic Fluids | Port Type: | NPT |
| Highlight: | SUN Overflow Valve,System Pressure Control Overflow Valve,Smooth Pump Start-Up Overflow Valve |
||
Product Description
Air-bleed and start-up cartridges are used to purge air trapped in the system to help reduce power requirements and facilitate pump priming during the start-up of blocked center circuits.
Air-bleed and start-up valves require a minimum of 4 gpm (15 L/min.) flow rate and 80 psi (5,5 bar) system pressure.
The valve will re-open when system pressure falls below 25 psi (1,7 bar)
After air has been purged, closing times vary from approximately 12 seconds at 4 gpm (15 L/min.) to 0.5 seconds at 50 gpm 200 L/min.).
Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Brand | SUN |
| Model | NQEB-XAN |
| Cavity | T-3A |
| Series | 2 |
| Capacity | 4 - 50 gpm |
| Maximum Operating Pressure | 5000 psi |
| Valve Hex Size | 1 1/8 in. |
| Valve Installation Torque | 45 - 50 lbf ft |
| Model Weight | 0.39 lb. |
| Flow Rate | Ranges from 5 gpm to 30 gpm |
