| Place of Origin: | Denmark |
|---|---|
| Brand Name: | Danfoss |
| Certification: | cc |
| Model Number: | OSQB8 |
| Minimum Order Quantity: | 1 |
| Price: | RMB/1000-100000/PC |
| Packaging Details: | wooden case/carton |
| Delivery Time: | 3 work days |
| Payment Terms: | T/T |
| Supply Ability: | 10PCS/days |
| Valve Type: | Proportional Valve | Valve Size: | NG32 |
|---|---|---|---|
| Mounting Type: | Subplate | Adjustable Pressure Range: | 0-350 Bar |
| Response Time: | 10 Ms | Adjustable Flow Range: | 0-100% |
| Maximum Flow: | 160 L/min | Connection Type: | Threaded |
| Highlight: | Danfoss OSQB8 Flow Amplifier,Steel Flow Amplifier,24VDC Flow Amplifier |
||
Product Description:
Flow amplifier is a device that uses the adhesion effect when the fluid flows through the gradually expanding surface and combines the action of the adjacent airfoil to reduce the pressure and thus produce a large flow rate. Its core principle is based on the Coanda effect, which was discovered by Romanian inventor Henry Coanda in aerodynamic research.
Working principle of flow amplifier
The flow amplifier uses the adhesion effect when the fluid flows through the gradually expanding surface and combines the action of the adjacent airfoil to make the fluid produce a larger flow rate when it is ejected. Specifically, when the fluid flows through the gradually expanding surface, the flow velocity increases and the static pressure decreases, thereby forming a larger flow rate at the injection port. This effect enables the flow amplifier to produce a larger flow output at a smaller driving pressure.
Features of flow amplifier
High efficiency : The flow amplifier can produce a larger flow at a smaller driving pressure and has a higher flow amplification ratio.
Simple structure : Its design usually includes a gradually expanding surface and an adjacent airfoil, and the structure is relatively simple, easy to manufacture and maintain.
Wide application : It is suitable for a variety of fluid media, including gas and liquid, and is suitable for various industrial application scenarios that require a large flow output.
Flow amplifier usage scenarios
Flow amplifiers are widely used in various industrial scenarios that require large flow output, such as pneumatic systems, hydraulic systems, and occasions that require precise flow control. Due to its high efficiency and simple structure, flow amplifiers have important application value in industrial production and scientific research.
| Control Voltage | 24 VDC |
| Control Signal | Proportional |
| Seal Material | Nitrile rubber |
| Material | Steel |
| Maximum Pressure | 350 bar |
| Valve Type | Proportional Valve |
| Valve Size | NG32 |
| Mounting Type | Subplate |
| Adjustable Pressure Range | 0-350 bar |
| Response Time | 10 ms |
